Solder Shield Shielded and Coaxial Cable Splices

Application

SA series (Cable-to-Cable) offers a fast, reliable solution for splicing shielded or coaxial cables. It fully restores the shield’s integrity, effectively eliminating EMI vulnerabilities at the joint. Each unit integrates a CA series crimp splice for conductors and a flux-coated, solder-impregnated copper braid housed within a transparent heat-shrink sleeve. A single heating step solders the braid circumferentially to the cable shield, encapsulates the entire splice, and provides robust strain relief. The result is shield continuity that matches or exceeds the original cable specifications.

Series Overview

Universal product line accommodating various cable diameters and shield constructions.

• Multiconductor Shielded Cables: See Table A for selection criteria.

• Coaxial Cables: See Table B for selection criteria.

Features and benefits

• 360° EMI Shielding: Flux-coated, solder-impregnated braid ensures controlled soldering and complete shield restoration.

• All-in-One Encapsulation: Transparent sleeve offers insulation, inspection visibility, and mechanical reinforcement.

• Simplified Installation: One-piece design reduces complexity and total installed cost.

• Versatile Application: Ideal for fabrication, repair, and rework of coaxial and multiconductor cables.

Notes:

• Please contact us for detailed dimensions, cable compatibility tables, and part numbers.

• Custom braid types, sizes, and ground‑lead configurations are available on request. Specifications may change without prior notice. Minimum order quantities (MOQ) may differ from standard packaging quantities.
